.Extremely High Efficiency 100Lm/w
.Low voltage operation DC12V
.Super thin 3mm, ultra flat
.Water resistance ip67
.Various sizes or customized
.Good heat dissipation with aluminum
.Long Life-span: 50000hr
.Green Light: CE, RoHS approval
.Environment Friendly: non-toxic materials, recycled to minimize pollution.
.High Optical Efficiency: energy efficient 60% compared to fluorescent lamps.
.Uniform illumination: widely used for backlight or ceiling light
.Quality warranty: 3 Years
|
Model
|
Dimension
|
LED QTY
|
Lumen
|
Power
DC12V
|
LED spacing
Minimal depth required
|
|
RX-ALF5050-33-3030
|
300x300mm
|
81LED
|
1500Lm
|
15W
|
33.33mm
Min. Cabinet Depth* 48mm
|
|
RX-ALF5050-33-3060
|
300x600mm
|
162LED
|
3000Lm
|
30W
|
|
RX-ALF5050-33-6060
|
600x600mm
|
324LED
|
5800Lm
|
58W
|
|
RX-ALF5050-33-RGB-3030
|
300x300mm
|
81LED
|
405Lm
|
Max 15W
|
|
RX-ALF5050-25-1030
|
100x300mm
|
48LED
|
960Lm
|
9.6W
|
25mm
Min. Cabinet Depth* 36mm
|
|
RX-ALF5050-25-1060
|
100x600mm
|
96LED
|
1800Lm
|
18W
|
|
RX-ALF5050-25-2050
|
200x500mm
|
160LED
|
2800Lm
|
28W
|
|
RX-ALF5050-25-20100
|
200x1000mm
|
320LED
|
5600Lm
|
56W
|
|
RX-ALF5050-25-3030
|
300x300mm
|
144LED
|
2500Lm
|
25W
|
|
RX-ALF5050-25-3060
|
300x600mm
|
288LED
|
5000Lm
|
50W
|
|
RX-ALF5050-25-6060
|
600x600mm
|
576LED
|
10000Lm
|
100W
|
|
RX-ALF5050-16-660
|
60x600mm
|
3x36=108LED
|
2000Lm
|
20W
|
16mm
Min. Cabinet Depth* 25mm
|
|
RX-ALF5050-16-3030
|
300x300mm
|
324LED
|
5800Lm
|
58W
|
|
RX-ALF5050-16-2050
|
200x500mm
|
360LED
|
6500Lm
|
65W
|
|
RX-ALF5050-16-6060
|
600x600mm
|
1296LED
|
20000Lm
|
200W
|
Applications:
1. Outdoor / Indoor Backlighting
- Commercial advertising light boxes- Advertising signs cabinet- Advertising billboard, poster, signboard- Menu Light boxes- Bus shelter light boxes- Shopping mall light boxes- Airport/metro light boxes- Floor Backlit- Signage display etc.
2. Direct lighting:
- Hotels- Conference- Meeting rooms- Factories- Offices- Residential / Institution Buildings- Hospitals- Schools- Showroom etc.
3. DIY for your own projects
|
